Dehumidifiers
Desiccant dehumidifier MDC8000
Desiccant Technologies Group industrial desiccant dehumidifier MDC8000 designed for general purposes – room air dehumidification and process drying. The compact construction allows extended periods of operation with a minimum of maintenance. Especially suitable for low temperature and low humidity operation. Unit includes desiccant rotor, EC-fans, reactivation heater, filters and controls. Panels insulated with 40mm rock wool insulation.
Constructional Features:
- The casing is completely hermetic and panels are made of 1,0mm AluZinc sheet metal with isolation of 40mm (rock wool); it has high resistance to atmospheric corrosion. Powder painted panels (outside only); rigid frame made of 1,5mm AluZinc sheet metal (powder painted completely) to achieve rigidity
- Compact design and low weight of the unit
- High performance at low temperatures and low relative humidity in a room
- Optional humidistat is available as an accessory
- Microprocessor based control (optional)
- Tubular electric heating elements for regeneration (standard unit) as well as on request with water, steam or gas heating coil (customized unit)
- Easy access to the internal components of the dehumidifier for the maintenance
- EC-fans
- Pocket filters G4-F9
- High efficiency of the washable silica gel rotor
- All components made exclusively by European manufacturers
Technical data:
Process air
Rated airflow – 8000 m³/h
Available static pressure 280 Pа
Reactivation air
Rated airflow 2500 m^3/h
Available static pressure 150 Pа
Power supply (electric reactivation)
(3х400V, 50 Hz) 83 kW
Current 120 А
Power supply (steam/water/gas reactivation)
(3х400V, 50 Hz) 11 kW
Current 16 А
Miscellaneous data
Weight 1000 kg
Operating temperature -30/+40˚С
Max noise level
without ductworks 73 dBA
Air filter (pocket) EU4…EU9
IEC protective class IP55
Insulation 40mm
